Mid-Rise Scissor Lift----AK-X80
KATOOL Mid-Rise Scissor Lift ----AK-X80
Feature：
8000lbs(3500KG) lifting capacity
Pneumatic safety release
Drive up ramps lock design as platform extension for long vehicles
Mobile kit included makes the lift move in your garage very easy
Top level hydraulic system and aluminum motor with fan on top to avoid
overheating caused by long time working with 220V/60HZ/1PH and 110V/60HZ/1PH(Optional)
Mid-Rise Scissor Lift AK-X80 110V
|
Lifting Capacity
|
8000lbs.(3500KG)
|
|
Max. Lifting Height
|
41.25"/1050mm
|
|
Min. Height
|
4.25"/110mm
|
|
Plateform Length
|
56.25"/1430mm
|
|
Length Overall
|
80"/2036mm
|
|
Plateform Width
|
19.5"/500mm
|
|
Width Overall
|
73.25"/1860mm
|
|
Motor
|
110VAC/60HZ/1PH
|
|
Net Weight
|
550KG
|
Mid-Rise Scissor Lift AK-X80 220V
|
Lifting Capacity
|
8000lbs.(3500KG)
|
|
Max. Lifting Height
|
41.25"/1050mm
|
|
Min. Height
|
4.25"/110mm
|
|
Plateform Length
|
56.25"/1430mm
|
|
Length Overall
|
80"/2036mm
|
|
Plateform Width
|
19.5"/500mm
|
|
Width Overall
|
73.25"/1860mm
|
|
Motor
|
220VAC/60HZ/1PH
|
|
Net Weight
|
550KG
|
